Rubber Rolling Machine

Manufacturer: Vietnam.

Specifications:

Safety is a basic feature of the machine. Safety bars mounted on rolls are easily accessible in an emergency stop. It also has other safety devices, such as emergency switches, overload cutoffs and reverse rotation switches, Knee stop, Hand stop and Screen stop.

Model LT-D150L300.
Roll diameter (mm) 150.
Roll length (mm) 330.
Nip adjustment (mm) 0.1 – 20.
Previous roll speed (rpm) 0 – 40.0.
Rear roll speed (rpm) 0 – 40.0.
Reset speed before / after (rpm) 24 / 33.6.
Hardness of roll surface (HRC) 60.
Digital display Front scrolling speed, Rear scrolling speed, Nip distance.
Nip Gap Adjustment A manual rotation.
Motor / Transmission 4 KW x 2 / EU.
Inverter Made in EU.
Capacity 380 Volt / 50Hz.

• LT twin shaft mill consists of two rollers made of steel with hard chrome plating.
• Both running coils have variable speed and are set by the end user.
• Machine with electric control panel installed.
• The machine consists of two motors to transmit driving power to two independent windings.
